Pneum. punch machine Comall Reynaers (alu). Year: 2007.

Specification

Pneumatic punching unit for end processing aluminum profiles. The previous owner has used this pneumatic punching unit to punch holes, slots in REYNAERS aluminium profiles (see photos for more information aboute the profile that have been cut and the tool stations). Can easily be rebuilt according to your own needs.

Cylinder Ø: 200 mm

Stroke length: 10 mm

Work pressure: 6 bar

Press force: 1740 kg

Air consumtion: 3,7 L/per cycle

Station 1: Slot puncher 30x6 mm

Station 2: Slot puncher 30x6 mm **

Station 3: Slot puncher 20x5 mm

Station 4: Hole puncher Ø6 mm + slot puncher 11x5 mm

Tool in machine are for following REYNAERS profiles: 006.1001xx, 006.1007.xx, 006.1009.xx, 006.1021.xx, 006.1016.xx, 006.1022.xx (** also for 006.1050.xx & 006.2086.xx)
